PACKARD INC Packard 1/4 HP 115V 43783
Product Specification
| Specification | Value |
|---|---|
| Part Number | 43783 |
| Motor Type | PSC (Permanent Split Capacitor) |
| Application | Condenser Fan Motor |
| Horsepower | 1/4 HP |
| Voltage | 115V |
| Speed | 1075 RPM |
| Full Load Amps | 3.60 A |
| Enclosure | Open Air Over |
| Duty | Continuous, Air Over |
| Bearing | Sleeve |
Description
The 43783 is a 1/4 HP 115V permanent split capacitor condenser fan motor for residential and commercial HVAC condensing units. Operating at 1075 RPM, it drives the condenser fan blade that pulls air across the coil fins to reject heat from the refrigerant circuit and keep the system running efficiently. A failed condenser fan motor causes the outdoor unit to trip on high-pressure lockout - replacing it with the 43783 restores normal operation and protects the compressor from heat damage.
